Note: Repeat this substep for all
hosts.
5.2.6 Enabling Zoning using Windows
1. From the host server, identify the SCSI devices that are associated with the Ultrastar Data60 IOMs.
Note: The operating system associates each SEP device as a SCSI device. The SCSI device of
the SEP can be used to get status from or control elements within the enclosure.
a) Issue the following command:
sg_scan -s | findstr /i H4060-J
b) Identify the SCSI devices from the output. The device information follows SCSI0. The devices appear
as SCSI0:1,62,0 and SCSI0:1,124,0 bolded in the example below.
SCSI0:1,62,0 claimed=0 pdt=dh HGST H460-J 0101
0428
SCSI0:1,124,0 claimed=0 pdt=dh HGST H460-J 0101
0428
2. Locate the IP Address for each IOM using sg_ses page 7.
a) Issue the following command:
sg_ses <dev> -p7 | finstr /i esce
Note: For scsi<dev>, type the number of the SCSI device recorded in the previous
step.
b) The IP Address for each IOM will appear at the end of each resulting line. Each IP Address is labeled
for either IOM A or IOM B and occurs after the last comma as seen bolded in the following example.
3. Verify the IOM SAS Address that matches each SCSI device that is linked to each IOM using sg_vpd page
83h.
a) Issue the following command:
sg_vpd <dev> -p0x83
b) Identify and match the IOM SAS address and sg device for both IOMs from the output. Each address
appears bolded in the example below.
Addressed logical unit:
designator type: NAA, code set: Binary
0x5000ccab0300003c
Target port:
designator type: NAA, code set: Binary
transport: Serial Attached SCSI Protocol (SPL-4)
0x5000ccab0300003c
