3.5 IOM Fan Description
Figure 21: Overview Image
The IOM Fan is designed to focus cooling on the enclosure's IOMs. It is installed in the central chassis bay
and is accessed from the top of the enclosure underneath the lid. It is attached to the chassis toolless release
mechanism that allows for easy replacement.
3.5.1 IOM Fan Specifications
Table 25: Specification Summary
ValueSpecication
1Number per Enclosure
1EX0432Part Number
YesHot Swappable?
CRUFRU or CRU?
181.4 g / .4 lbsWeight
43
3 Component Overviews
User Guide 3.5 IOM Fan Description
