3.8 Drive Assembly Description
Figure 29: Overview Image
The Drive Assembly is comprised of two parts: the storage drive and the drive carrier. The carrier attaches
to the exterior of the data storage drive and caddies the drive into the enclosure. It stabilizes the motion of
the drive into the drive bay so that the drive properly mounts onto the drive board.
3.8.1 Drive Assembly Specifications
Table 31: Specification Summary
ValueSpecication
up to 60 drivesNumber per Enclosure
See the List of Compatible Drives on page 23 to nd
the specic part number required.
Part Number
YesHot Swappable?
.68 kg / 1.5 lbs.Weight
51
3 Component Overviews
User Guide 3.8 Drive Assembly Description
