DTS-60A OPERATORS MANUAL
98
Appendix I – Test Programs Script Files
Standard Electrodes Procedures
Shape and
Dimensions
Spacing Tolerance Rate of
Rise
Start-up
Wait
Timer
Start-up
Stirrer
Timer
Stages /
not
evaluated
A
fter
BD Wait
Timer
A
fter BD
Stirrer
Timer
IEC 156/95 Type I/II 2.5 mm
 0.05 mm 2  0.2
5 min 5 min 6 / - 2 min 2 min
IEC 156/63 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
NBN C27-002 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
NEN 10 156 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
SEV 314/69 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
BS 5874/1980 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
VDE 370 - P5/92 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
UNE 21 309/70 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
A
S 1767/75 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
SABS 555/76 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
UTE C27-221/74 Type I/II 2.5 mm
 0.1 mm
2 10 min - 6 / 1 5 min 1 min
CEI 10-1/73 Type II 2.5 mm
 0.1 mm
2 10 min - 6 / - 5 min 1 min
VDE 0370-P1/78 Type II 2.5 mm
 0.05 mm
2 10 min - 6 / - 2 min 1 min
IRAM 2341/72 Type I/II 2.5 mm
 0.05 mm
2 10 min - 6 / 1 2 min 1 min
prg 0 new IEC-156/95 2.5 0.05 mm type_I_II 00:05:00 00:05:00 06
prg 0 stage 00 002.0 kV/s breakdown 00:10:00 00:02:00 00:02:00 next store
prg 0 stage 01 002.0 kV/s breakdown 00:10:00 00:02:00 00:02:00 next store
prg 0 stage 02 002.0 kV/s breakdown 00:10:00 00:02:00 00:02:00 next store
prg 0 stage 03 002.0 kV/s breakdown 00:10:00 00:02:00 00:02:00 next store
prg 0 stage 04 002.0 kV/s breakdown 00:10:00 00:02:00 00:02:00 next store
prg 0 stage 05 002.0 kV/s breakdown 00:10:00 00:02:00 00:02:00 end store
prg 0 end mean_yes print_yes
prg 1 new IEC-156/63 2.5 0.1 mm type_I_II 00:10:00 00:00:00 06
prg 1 stage 00 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 1 stage 01 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 1 stage 02 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 1 stage 03 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 1 stage 04 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 1 stage 05 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 end store
prg 1 end mean_yes print_yes
prg 2 new UTE_C27221/74 2.5 0.1 mm type_I_II 00:10:00 00:00:00 06
prg 2 stage 00 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next
prg 2 stage 01 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 2 stage 02 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 2 stage 03 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 2 stage 04 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 2 stage 05 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 end store
prg 2 end mean_yes print_yes
prg 3 new CEI_10-1/73 2.5 0.1 mm type_II 00:10:00 00:00:00 06
prg 3 stage 00 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 3 stage 01 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 3 stage 02 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 3 stage 03 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 3 stage 04 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 next store
prg 3 stage 05 002.0 kV/s breakdown 00:10:00 00:05:00 00:01:00 end store
prg 3 end mean_yes print_yes
prg 4 new VDE_0370-1/78 2.5 0.05 mm type_II 00:10:00 00:00:00 06
prg 4 stage 00 002.0 kV/s breakdown 00:10:00 00:02:00 00:01:00 next store
prg 4 stage 01 002.0 kV/s breakdown 00:10:00 00:02:00 00:01:00 next store
prg 4 stage 02 002.0 kV/s breakdown 00:10:00 00:02:00 00:01:00 next store
