DTS-60A OPERATORS MANUAL
30
Figure 3-2 – Simple Test Startup/Electrodes Spacing Warning Message
The user might adjust the electrode spacing before starting the test. In
such cases he will open the lid, in order to have access to the electrodes
adjustment. The latter action is immediately detected by the system and a
warning message for the open lid is displayed, Figure 3-3.
Figure 3-3 – Open Lid Warning Message
3.3 Simple Test Controls
After adjusting the electrodes and closing the hood, the system will still
be halted until the user presses the ‘ENTER’ key. Then system enters the
GO TO MENU
VERIFY ELECTRODE/
GAP SPACING!
MENU
Simple Test Indication
Adjustable Voltage/sec
Stage Duration Timer
Warning Message!
Key Help Message for go to menu
PROCEED TEST
VERIFY ELECTRODE/
GAP SPACING!
ENTER
Key Help Message for
start test execution
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
Lid is open!
12:10 01/08/05 65 °F
Time, Date and
Environmental Temperature
Warning Message!
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
