DTS-60A OPERATORS MANUAL
78
7.3 Printout Description
After the end of an executed test the systems prompts the user for
printing a receipt. In Fig. 7-7 is depicted the printed information.
1. High-Voltage Logo
2. User (Operator) information
3. Time and Date
4. Environmental temperature
5. Test Name
6. Electrodes
7. Number of Breakdowns
8. Mean Value of Breakdown Voltages
9. Standard Deviation of Breakdown Voltages
10. Stages/ Starting Voltage/ Ending Voltage/ Duration/ Breakdown
----------------------------------------
HighVoltage, INC.
DTS-60A Test Report
----------------------------------------
Operator
Company : HighVoltage
Name : John Smith
Contact : +30-210-9319505
Info : smith@hvinc.com
----------------------------------------
Report ID : 1018
----------------------------------------
Time : 14:41:14
Date : 24/01/2005
Temperature : 19 ·C
Test Name : SIMPLE TEST
Electrodes : Unknown
Num. Breakdown : 5
Mean Breakdown : 50.61
Std Breakdown : 6.24
Stage 1: 0.5kV/s, 0.0> 48.1kV, Breakdown
Stage 2: 0.5kV/s, 0.0> 40.7kV, Breakdown
Stage 3: 0.5kV/s, 0.0> 54.9kV, Breakdown
Stage 4: 0.5kV/s, 0.0> 54.3kV, Breakdown
Stage 5: 0.5kV/s, 0.0> 55.1kV, Breakdown
----------------------------------------
Figure 6-7 – Printout Receipt
