DTS-60A OPERATORS MANUAL
34
Figure 3-8 – Test Results
3.5 Simple Test Example
A detailed example is illustrated in the figure 3-8 a/b/c/d.
Figure 3-8a – Simple Test Example
TEST RESULTS
PRESS ANY KEY...
PROGRAM: SIMPLE TEST
NUM. BD: 4
MEAN: 22.44
STD: 14.61
Number of Detected Breakdowns
Mean Value of Breakdown Voltages
Standard Deviation of Breakdown Voltages
GO TO MENU
VERIFY ELECTRODE/
GAP SPACING!
Lid is open!
0.0
kV
STEP 1
Verify Electrode/Gap Spacing Warning!
The user must be sure that the electrodes confirm
the test requirements (described in spesific
Standards).
The last line depicts help messages!
STEP 2
Lid is open!
As the user opens the LID, in order to make
adjustments the system displays the current
warning message.
STEP 3
STEP 4 UP
As soon as the user closes the LID the system will
proceed the the Simple test main screen.
The rate of rise selection is BLINKING, which
indicates that the user must set this item.
Use the UP and DOWN keys to select the desired
output voltage rate of rise.
0.0
kV
DOWN
12:10 01/08/05 65 °F
12:10 01/08/05 65 °F
12:10 01/08/05 65 °F
MENU
STAGE
1
STAGE
1
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.1 kV/s
TEST:SIMPLE TEST
TIMER:
00:00:00
VOLTAGE:
0.5 kV/s
