5.4 Script Files for Tests
In order to achieve a faster method for updating the equipment’s Tests,
an alternative method is supported. The method is based on Script
Test Program Files, that the user could develop using an editor on a
Personal Computer (PC). The following paragraphs explain the
commands and arguments of the specific script files. Furthermore two
examples are presented. The Script Test Files downloading to the
equipment is described in chapter 8 (Remote Operation).
5.4.1 Script File Commands and Arguments
The Script Test Program Files are based on the following command
structure:
new – Start a new Script Test Program File
stage – End of a new Script Test Program File
end - Start Test Program Information Session
PRG
program ID
command
command = new
program name
electrode gap value
electrode gap error
electrode gap units
electrode type
startup IDLE timer
startup STIRRER timer
number of stages
command = stage
stage ID
Voltage Value
Voltage Type
Stage Duration
Stirrer Timer
After Breakdown IDLE timer
After Breakdown STIRRER timer
After Breakdown Stage
Store Breakdown Voltage
command = end
statistics
printout
Figure 5-12 – Structure of the Script File
The above script file commands operate in respect with the parameters
described in paragraph 5.1.1 and 5.1.2.
