DTS-60A OPERATORS MANUAL
14
1.4 Setup the Equipment
The setup of this equipment has been minimized by careful
consideration of the operator during design. The DTS-60xx one-piece
construction permits convenient portability. The DTS-60xx test set
requires that the unit is operated with the control panel in the
horizontal position, to keep oil level over high voltage transformer in
the high voltage tank.
1. Select a location for the unit that will allow easy
viewing of the User Interface
2. Be sure that all the controls are off, in their de-
energized state.
3. Remove all components and oil vessels from the test
chamber
4. Install the input line cord into the Input Power
receptacle
5. Connect the line cord to a suitable (120V or 230V,
see Specifications Table) grounded power source.
6. Select the desired Test cell. Fill in with sufficient
insulating liquid for the testing to be performed.
7. Clean the Test Cell and Electrodes thoroughly and
adjust the electrodes to conform with the proper ASTM
Specification. Be sure the electrodes are securely
tightened on the adjustment posts inside the oil vessel.
Use Isolation transformer (1/1) if the
electrical installation has neutral
earthing.
All the oil vessels designed and made by High
Voltage Inc.
have interchangeable posts and electrodes. These
oil
vessels were designed to conform to the ASTM test
To Next Page
