DTS-60A OPERATORS MANUAL
1
1
Specifications and Controls
This section familiarizes the operator with the features and the
specifications of the DTS-60A AC Dielectric Oil Test Set manufactured
by High Voltage, inc. Moreover, a brief introduction about the
equipment’s set-up and start-up is presented.
1. Features and Specifications 1-2
2. Control Panel
1-4
3. User Interface
1-5
1. Menu Overview 1-5
2. Keyboard Operations 1-6
3. Warning Messages 1-8
4. Question Messages 1-10
5. Error Messages 1-12
6. Indicators 1-13
4. Setup the Equipment
1-14
5. Using the Shielded Output Cables 1-15
6. Startup the Equipment
1-16
