DTS-60A OPERATORS MANUAL
10
1.3.4 Question Messages
The unit may display the following Question Messages.
1. Continue Test?, Figure 1.7.
This question message is displayed after a breakdown
detection in the Simple Test procedure. The system
prompts the user for continuing the current test with a new
stage, or terminating the test. User may press the ‘ENTER’
key for continuing the test, or the ‘BACK’ key for
terminating the test. All other keys are disabled.
Question Message
PROGRAM: SIMPLE TEST
12:10 01/08/05 65 °F
Continue Test?
Yes:
No:
VOLTAGE: 0.5 kV/s
DURATION: 00:00:30
?
ENTER
BACK
Figure 1.7 – ‘Continue Test?’ Question Message
2. Print Results?, Figure 1.8.
This question message is displayed only if the equipment
has a printer. The message prompts the user for printing
the test report after a test is finished. User may press the
‘ENTER’ key for printing the test report, or the ‘BACK’ key
for discarding the printing. All other keys are disabled.
Question Message
PROGRAM: SIMPLE TEST
12:10 01/08/05 65 °F
Print Results?
Yes:
No:
VOLTAGE: 0.5 kV/s
DURATION: 00:00:30
?
ENTER
BACK
Figure 1.8 – ‘Print Results?’ Question Message
