DTS-60A OPERATORS MANUAL
3
Table 1.1 - Specifications
DTS – 60A
Input 120V, 50/60 Hz, 5 amps, single phase
230V, 50/60 Hz, 3 amps, single phase
Output 0 – 60kVac, 800VA resistive load, between bushings
Output Termination Dual Capacitively Graded Bushings
Display Dot-Matrix 128x64
Keyboard 5 keys for equipment’s functionalities
Printer Optional 40 columns dot-matrix
Remote Management RS-232 Serial Interface
Breakdown Shutdown Less than 5 ms
Accuracy 0.5%
Operating
Temperature
-14 F to 104 F (-10 C to 40 C)
Case Size 14.75w x 14d x 11.5h in (36.88w x 35d x 28.75h mm)
H.V. Tank High Voltage Tank Included
Weight 60 lbs.
