HIKVISION DS-7104HGHI-F1 User Manual

Digital Video Recorder User Manual
134
Figure 6-11 Tag Management Interface
Steps
Step 1 Select Tag from the drop-down list in the Playback interface.
Step 2 Choose channels, edit start time and end time, and then click Search to enter Search Result
interface.
You can enter keyword in the textbox to search the tag on your command.
Figure 6-12 Video Search by Tag
Step 3 Click button to play back the file.
You can click the Back button to return to the search interface.

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
