Digital Video Recorder User Manual
72
Step 2 You can edit the IP address, protocol, management port, and other information of the IP
camera to be added.
If the IP camera to add has not been actiavated, you can activate it from the IP camera list on the
IP Camera Management interface.
Step 3 Click Add to add the camera.
For the successfully added IP cameras, the Security status shows the security level of the
password of camera: strong password, weak password and risky password.
Figure 2-42 Successfully Added IP Cameras
Please refer to Chapter 18.1 Specifications for the number of connectable IP cameras for different
models.
Table 2-1 Explanation of the icons
Icon
Explanation
Icon
Explanation
Edit basic parameters of
the camera
Add the detected IP camera.
The camera is
disconnected; You can click
the icon to get the
exception information of
camera.
Delete the IP camera
Play the live video of the
connected camera.
Advanced settings of the
camera.

HIKVISION DS-7104HGHI-F1 Specifications

General

Video Compression	H.264
Video Input	4 channels
Audio Input	1 channel
Audio Output	1 channel
HDD Interface	1 SATA interface
HDD Capacity	Up to 6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Operating Temperature	-10 °C to +55 °C
Operating Humidity	10% to 90%
Video Output	1 VGA, 1 HDMI
Network Interface	1 RJ45 10M/100M Ethernet interface
