LED Color/Status Description
STA
(expansion
module)
Green/Always on The expansion module is booting.
Green/Blinking The expansion module is running normally.
Red/Always on The expansion module has failed to boot or has
an error.
SG-6000-X8180 LED Indicators Description is shown as below:
LED Color/Status Description
PWR Green/Always on The device power is running normally.
Orange/Always on The device power is running abnormally.
Red/Always on Power failure so the system is down.
Off The device is powered off.
STA Green/Always on The system is booting.
Green/Blinking The system is running normally.
Red/Always on The system has failed to boot or has an error.
ALM Red/Always on The system is sending alarm(s).
Green/Blinking The system is waiting.
Orange/Blinking The system is using a trial license.
Orange/Always on The trial license has expired and there is no
legitimate license installed in the system.
Off The system is running normally.
Chapter 1 Product Profile 13
