4.2 Setting the Parameters to be Displayed
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
NOTE
3. The parameter which you wish to display in the chosen position can be
chosen from the following list by pressing the corresponding key. The
screen will then automatically revert to the Initial screen, with the desired
new parameter being displayed in the appropriate position.
Z impedance (Ω)
Y
admittance (S)
θ impedance phase angle ( )*1
Cs static capacitance in series equivalent circuit mode (F)
Cp static capacitance in parallel equivalent circuit mode (F)
D loss coefficient=tanδ
Ls inductance in series equivalent circuit mode (H)
Lp inductance in parallel equivalent circuit mode (H)
Q Q factor
R
s effective resistance in series equivalent circuit mode (Ω)=ESR
R
p effective resistance in parallel equivalent circuit mode (Ω)
G conductance (S)
X
reactance (Ω)
B susceptance (S)
OFF display no test parameter in the chosen position
*1 The phase angle θ is shown based on the impedance Z. When
measuring based on the admittance, the sign of the phase angle θ must
be reversed.
All parameters excluding the impedance phase angle θ is displayed as
absolute value. To check the polarity, confirm the impedance phase angle θ .
For details, see Section 7.2, "Testing Parameters and Calculation Equations".
Press the key in order to cancel this setting process and return to the
Initial screen with the original parameter still displayed as before.
