4.13 Setting the Testing Speed
______________________________________________________________________________________________
4.13.2 Details of the Setting Process
Initial screen
Menu screen
The test speed currently set is displayed.
FAST key
NORM key
SLOW key
SLOW2 key
Test S
p
eed Settin
g
Screen
Testing speeds (typical)
FAST 5ms 2ms Low accuracy testing at high speed
NORM 21 ms 2ms This speed used for normal testing
SLOW 72 ms 2ms High accuracy slow testing
SLOW2 140 ms 2ms High accuracy slow testing
1. Press the key on the Initial screen to display the Menu screen.
2. Press the key on the Menu screen to display the Test speed setting
screen.
3. Select the desired new speed for testing from among the following options.
The key corresponding to the currently selected testing speed appears in non-
reversed video (black letters upon a white ground).
The testing speed varies according to the number of parameters being
displayed, and according to their type. The speeds given in the table relate
to the case of |Z| only being displayed. For details, refer to Section 7.3,
"Time Taken for Testing."
4. When the setting has been established as above, press the key to return
to the Initial screen.
