4.14 Setting the Measurement Cable Length
______________________________________________________________________________________________
4.14.1 Control Screen Sequence
Initial screen
Initial screen
Menu screen
Cable length setting screen
4.14 Setting the Measurement Cable Length
In measuring harmonics, the cable has a large influence on the
measurement error. Making the cable length setting enables the
measurement error to be reduced.
Press the key.
Press the key.
Set the cable length.
When the setting has been established, press the
key to return to the Initial screen.
The setting has been made.
