4.2 Setting the Parameters to be Displayed
______________________________________________________________________________________________
4.2.1 Control Screen Sequence
Initial screen
Parameter setting screen
Initial screen
4.2.2 Details of the Setting Process
The position in which you wish to
change the parameter displayed
The parameter currently being displayed in this position
appears in black letters on white (non-reversed video).
Press this key to
abandon the setting
process and return
to the Initial screen.
4.2 Setting the Parameters to be Displayed
From among the total of 14 different test parameters a maximum of four can
be selected for their values to be simultaneously displayed on the screen,
arranged in any desired order.
Press the parameter key for which you wish to make the
change.
Press the key in the parameter list corresponding to the
parameter which you wish to display in that position.
The Initial screen will automatically be displayed again.
The parameter displayed in that position will now be
the desired one.
1. Ensure that the Initial screen is being displayed.
2. Decide in which of the four positions on this Initial screen you wish to
change the parameter which is being displayed, and then press the parameter
key in the corresponding position.
The Parameter setting screen will be displayed, as follows:
The parameters set to be displayed can only be changed by starting from the
Initial screen.
