Fuse Replacement
6.4 Fuse Replacement
If the fuse is blown, replace it with a new one.
The fuses can be purchased via authorized Hioki distributor or
reseller.
See: “4 Check that the fuse is not blown.” (p. 57)
See: “Fuse replacement procedure” (p. 138)
WARNING
Use only fuses of the specied type,
characteristics, rated current, and voltage.
Specied fuses: For A terminal, 11 A/1000 V
Breaking capacity: 50 kA AC/30 kA DC, fast-blow type,
diam. 10.3 × 38 mm, manufactured by Hollyland
Do not use any other fuse (particularly not a fuse with a
higher rated current).
Do not use the instrument with the fuse holder’s
terminals shorted.
Before removing the battery cover,
disconnect the instrument from the object
under measurement and set the rotary
switch to OFF.
Failure to do so could cause electric shock. When
the instrument is connected to the object under
measurement, the battery contacts are regarded as
high-voltage parts.
