Hioki DT4261 - Z3210 Wireless Adapter Installation Procedure

42
Installing Wireless Adapter
Z3210 Wireless Adapter installation procedure
Read the precautions before performing the procedure. (p. 41)
You will need
• Phillips screwdriver (No. 2), at-head screwdriver or coin
• Z3210 Wireless Adapter (option)
OFF
22
11
1
Remove the test leads from the
instrument.
2
Set the rotary switch to OFF.
3
Release the locks for the battery cover.
Turn the locks 180° in the counterclockwise direction using the
screwdriver or coin to align [UNLOCKED] with the

symbol (2 places).
Rear
LOCKED
UNLOCKED
LOCKED
UNLOCKED
LOCKED
UNLOCKED
LOCKED
UNLOCKED
Lock
