Preparing for Measurements
2.1 Measurement Procedure
Before using the instrument, be sure to read “Precautions for Use” (p. 13).
Installation and connection
As necessary, have other
optional items available and
ready.
To use the instrument
safely, be sure to select a
measurement function before
connecting the test leads to
the object to be measured.
11
33
Black
Red
22
44
Insert batteries (p. 30).
Perform inspection before use (p. 51).
Measurement
Turn the power on and select the
measurement function.
Connect the test leads to the
measurement terminals (p. 35).
As necessary, perform zero adjustment (p. 84).
Connect the test leads to the object to
be measured.
(As necessary)
Retain the measured value (p. 75).
End
Move the test leads away from the object under measurement and
then turn o the power.
2 Preparing for Measurements
