Hioki DT4261 - Measuring with the Manual Range

74
Measurement Range Selection
Measuring with the manual range
A range is selected manually.
Press
[RANGE: MANUAL] lights up
Each time
is pressed, an upper range is
specied.
When
is pressed continuously, the range
is switched to [AUTO] (auto range) after the
highest range.
When
is pressed during measurement at
the highest range, the lowest range is specied
once again.
Example: When the range is 6.000 V to 1000 V
6.000 V 60.00 V 600.0 V
1000 VAUTO
Switching from the manual range to the auto range
Press for at least 1 second.
HIOKI DT4261A961-00
