58
Voltage Measurement
3.2 Voltage Measurement
AC voltage, DC voltage, and DC/AC composite voltage
measurement can be performed. Additionally, the maximum,
minimum, average, and peak values of the measured values can be
checked. (p. 82)
WARNING
Do not use the instrument to measure
circuits that exceed the ratings or
specications of the instrument.
Doing so could cause damage to the instrument or
overheating, resulting in bodily injury.
• The autoranging function of the instrument automatically selects
the optimum measurement range. To change the range arbitrarily,
use the manual range (p. 74).
• Displayed values can frequently uctuate due to induction
potential even when no voltage is applied. This, however, is not a
malfunction.
• The 600 mV range is available only for DC voltage measurement.
