72
Measurement with Clamp On Probe (AC Current)
When clamping a cable
IMPORTANT
Clamp the instrument around only one wire of the conductor.
Regardless of the single-phase and three-phase, when clamping
around two or more wires together in a bundle, the load current
cannot be measured.
OK
NO
NONO
OK NO
NO NO
Do not clamp the
instrument around two
or more conductors.
Do not pinch
the conductor.
When the measured value and [OVER] blink
The measured value has exceeded the maximum display counts.
Increase the range by one step.
