Hioki DT4261 - Page 9

3
Options
Connection cables
L4933*
3
Contact Pin Set
L4934*
4
Small Alligator Clip Set
L4935*
2
Alligator Clip Set
L9243*
5
Grabber Clip
L4936*
6
Bus Bar Clip Set
L4937 Magnetic Adapter Set *
7
9804 Magnetic Adapter*
10
L4932*
1
Test Pin Set
L9207-10*
1
Test Lead
L4930*
2
Connection Cable Set
(Length: 1.2 m)
L4931*
2
Extension Cable Set
(Length: 1.5 m, with the
coupling connector)
L4938*
8
Test Pin Set
L4939*
9
Breaker Pin Set
L9300*
1
Test Lead
When attaching the L4933 or L4934 to a test
lead, do so in the measurement category II
conguration (for the L9207-10, with the sleeve
removed).
*1: CAT IV 600 V, CAT III 1000 V, CAT II 1000 V, 10 A
*2: CAT IV 600 V, CAT III 1000 V, 10 A
*3: 30 V AC, 60 V DC, 3 A
*4: CAT III 300 V, CAT II 600 V, 3 A
*5: CAT II 1000 V, 1 A
*6: CAT III 600 V, 5 A
*7: CAT III 1000 V, 2 A
*8: CAT III 600 V, CAT II 600 V, 10 A
*9: CAT III 600 V, 10 A
*10: CAT IV 1000 V, 2 A
HIOKI DT4261A961-00
