[INST(IN)09-02-90]
Figure 9-17 X-Path Cable Routing Example (1/2)
HSNBX-1
HSNBX-0
DKC-0
DKC-1
Figure 9-18
①
X-path Cable
(Optical)
X-path Cable
(Optical)
Clamp Tape
Rear view of rack
Rev.0.1
INST(IN)09-02-90
