(2) Optical X-path cable routing
A routing example of the optical X-path cables is shown in the gure below.
Figure 9-15 X-Path Cable Routing Example (1/2)
HSNBX-1
HSNBX-0
DKC-0
DKC-1
Figure 9-16
①
X-path Cable
(Optical)
Rear view of rack
X-path Cable
(Optical)
Clamp Tape
Figure 9-16 X-Path Cable Routing Example (2/2)
DKC-2
DKC-3
DKC-4
DKC-5
Figure 9-15
①
X-path Cable (Optical)
