[INST(IN)09-02-70]
2. X-path cable routing
(1) Copper X-path cable routing
A routing example of the copper X-path cables is shown in the gure below.
Figure 9-14 X-Path Cable Routing Example
X-path cable
HSNBX-1
HSNBX-0
DKC-1
DKC-0
MCC2/MCC45
MCC1/MCC60
Rear view of rack
