Table 2-6 Right and Left Side Clearance (a) for Floor Load Capacity of 4,410 Pa (450 kgf/m
2
)
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 200 mm or more 200 mm or more 200 mm or more
450 ≤ x < 550 200 mm or more 200 mm or more 200 mm or more
550 ≤ x < 650 200 mm or more 200 mm or more 200 mm or more
650 ≤ x < 750 200 mm or more 200 mm or more 200 mm or more
750 ≤ x < 850 200 mm or more 200 mm or more 200 mm or more
850 ≤ x 210 mm or more 200 mm or more 200 mm or more
Table 2-7 Right and Left Side Clearance (a) for Floor Load Capacity of 4,900 Pa (500 kgf/m
2
)
or more
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 200 mm or more 200 mm or more 200 mm or more
450 ≤ x < 550 200 mm or more 200 mm or more 200 mm or more
550 ≤ x < 650 200 mm or more 200 mm or more 200 mm or more
650 ≤ x < 750 200 mm or more 200 mm or more 200 mm or more
750 ≤ x < 850 200 mm or more 200 mm or more 200 mm or more
850 ≤ x 200 mm or more 200 mm or more 200 mm or more
