Table 2-3 Right and Left Side Clearance (a) for Floor Load Capacity of 2,940 Pa (300 kgf/m
2
)
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 200 mm or more 200 mm or more 200 mm or more
450 ≤ x < 550 200 mm or more 200 mm or more 200 mm or more
550 ≤ x < 650 250 mm or more 200 mm or more 200 mm or more
650 ≤ x < 750 380 mm or more 310 mm or more 250 mm or more
750 ≤ x < 850 500 mm or more 430 mm or more 360 mm or more
850 ≤ x 630 mm or more 540 mm or more 470 mm or more
Table 2-4 Right and Left Side Clearance (a) for Floor Load Capacity of 3,430 Pa (350 kgf/m
2
)
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 200 mm or more 200 mm or more 200 mm or more
450 ≤ x < 550 200 mm or more 200 mm or more 200 mm or more
550 ≤ x < 650 200 mm or more 200 mm or more 200 mm or more
650 ≤ x < 750 230 mm or more 200 mm or more 200 mm or more
750 ≤ x < 850 340 mm or more 280 mm or more 220 mm or more
850 ≤ x 450 mm or more 380 mm or more 320 mm or more
Table 2-5 Right and Left Side Clearance (a) for Floor Load Capacity of 3,920 Pa (400 kgf/m
2
)
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 200 mm or more 200 mm or more 200 mm or more
450 ≤ x < 550 200 mm or more 200 mm or more 200 mm or more
550 ≤ x < 650 200 mm or more 200 mm or more 200 mm or more
650 ≤ x < 750 200 mm or more 200 mm or more 200 mm or more
750 ≤ x < 850 220 mm or more 200 mm or more 200 mm or more
850 ≤ x 310 mm or more 250 mm or more 200 mm or more
