(3) Reference matrix of clearances between racks
Values of the right and left side clearance (a) and the front and rear side clearance (b) that are
illustrated in Figure 2-3 are shown by total weight of the storage system in the following tables.
Find a value of the necessary right and left side clearance (a) according to the expected front and
rear side clearance (b) (1,600/1,800/2,000 mm) for the installation location and the calculated total
weight of the storage system (x).
Table 2-1 Right and Left Side Clearance (a) for Floor Load Capacity of 1,960 Pa (200 kgf/m
2
)
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 310 mm or more 250 mm or more 200 mm or more
450 ≤ x < 550 510 mm or more 430 mm or more 370 mm or more
550 ≤ x < 650 700 mm or more 610 mm or more 530 mm or more
650 ≤ x < 750 890 mm or more 790 mm or more 700 mm or more
750 ≤ x < 850 1080 mm or more 970 mm or more 870 mm or more
850 ≤ x 1270 mm or more 1140 mm or more 1030 mm or more
Table 2-2 Right and Left Side Clearance (a) for Floor Load Capacity of 2,450 Pa (250 kgf/m
2
)
Total weight of storage system
(x) (unit: kg)
Right and left side clearance (a)
When the front and
rear side clearance (b)
is 1,600 mm or more
When the front and
rear side clearance (b)
is 1,800 mm or more
When the front and
rear side clearance (b)
is 2,000 mm or more
x < 250 200 mm or more 200 mm or more 200 mm or more
250 ≤ x < 350 200 mm or more 200 mm or more 200 mm or more
350 ≤ x < 450 200 mm or more 200 mm or more 200 mm or more
450 ≤ x < 550 280 mm or more 220 mm or more 200 mm or more
550 ≤ x < 650 430 mm or more 360 mm or more 300 mm or more
650 ≤ x < 750 580 mm or more 500 mm or more 430 mm or more
750 ≤ x < 850 730 mm or more 640 mm or more 560 mm or more
850 ≤ x 880 mm or more 780 mm or more 690 mm or more
