[INST(IN)09-04-70]
Table 9-12 Color List of Cable Color Codes
Content Location Label Color Color Name Remarks
PATH No.
(DKC-0/2/4)
PATH#1 Red
PATH#2 Orange
PATH#3 Yellow
PATH#4 Green
PATH#5 Light blue
PATH#6 Blue
PATH#7 Purple
PATH#8 Pink
PATH No.
(DKC-1/3/5)
PATH#1 Red With oblique lines.
PATH#2 Orange With oblique lines.
PATH#3 Yellow With oblique lines.
PATH#4 Green With oblique lines.
PATH#5 Light blue With oblique lines.
PATH#6 Blue With oblique lines.
PATH#7 Purple With oblique lines.
PATH#8 Pink With oblique lines.
IN IN White No color for OUT.
