3. Connection of SAS Cables/NVMe Cables
Connect the SAS cables/NVMe cables by following the procedure below according.
Check the connection locations of the connectors referring to “Storage System Cable Diagram”
(LOC05-10).
Table 9-13 Types of SAS Cables/NVMe Cables
No. Model Shape
1 • DKC-F910I-SCCS/SCCSP
• DKC-F910I-SCQ1/SCQ1P
• DKC-F910I-SCQ1F/SCQ1FP
2 • DKC-F910I-SCQ5A/SCQ5AP
• DKC-F910I-MPC10/MPC10P+SQSFP/SQSFPP
• DKC-F910I-MPC20/MPC20P+SQSFP/SQSFPP
• DKC-F910I-MPC30/MPC30P+SQSFP/SQSFPP
• DKC-F910I-MPC1H/MPC1HP+SQSFP/SQSFPP
3 • DKC-F910I-NCCS
