Copyright © 2019, 2021, Hitachi, Ltd.
DKC910IHitachi Proprietary
[INST(IN)14-01-40]
Rev.1.1
INST(IN)14-01-40
START
(1)-0 Backup the current Cong to the maintenance PC.
(1)-1 Check the DKC Serial Number and remember them for later use in step (11), “System Tuning” (SVP02-18-10).
(1)-2 Turn off the “POWER ON/OFF” switch on the HSNPANEL.
(1)-3 Make sure the breaker is off (DKU and DKC). (If it is “on”, turn off the breaker after the SVP is shut down.)
<Breaker: (INST(AD)11-01-20), SVP Shut Down: (SVP01-200)>
(1)-4 If the PUBLIC (SNMP Web Console) or INTERNAL (other device) cables in the SVP are connected, disconnect them. Do
not disconnect other cables. (LOC04-50)
(2) Turn on the breaker (DKU and DKC) and wait for the SVP ready to use.
(Donʼt turn on the “POWER ON/OFF” switch on the HSNPANEL.)
<Power ON Procedure of Storage system:
(INST(GE)05-01-10)>
(3) Set the SVP PS ON/OFF INH switch (SVP RAS SW #1) on the SSVP to ON (lower position).
When the Additional SVP is installed, set the SVP PS ON/OFF INH switch (SVP RAS SW #1) on the SSVP1 to ON (lower
position).
(LOC03-40)
(SVP procedure)
(4) Set TOD
(At this time, “Communication Error” may occur. You can ignore the error.)
(INST(IN)14-02-10)
(SVP procedure)
(5) Execute the following procedures: (*6)
[Install micro-programs and conguration to the HD to the SVP]
(REP(RSVP)05-60)
step1: Connect to the SVP display from the Maintenance PC by the remote desktop.
step2: Prepare the media.
step3: Uninstall any additional software installed on the SVP such as Hitachi Remote Ops/C-Track and Anti-Virus client.
step4: Insert the media disk into the Maintenance PCʼs drive.
To Next Page
