step5: Enter the following command: \\tsclient\E\xxxxx.exe (*10) (enter).
* In the case Maintenance PCʼs media drive is “E:”.
Message is displayed:
“(SUP4186W) Initializing the SVP that is currently operating. Do you want to continue?”
Select Yes.
The following message is displayed:
“The SVP is running. The PC will be rebooted to stop the SVP. Please retry the setup after the PC reboots.”
Select Finish after check Yes in radio buttons.
SVP reboots....
After reboot one icon is displayed (OTHER USER) click OTHER USER icon and enter “Administrator” (user)
and password. (*9)
Follow the process on the screen.
Select [CD-R] to install conguration information from media, when the message CNF4061i.
Enter the key code of the conguration information when the message CNF4055i, and then click [OK]. (*8)
RAID Manager and OSSs are being installed at this step.
Do not change any parameters during install (leave unchanged values).
step6: Remove the media from the Maintenance PCʼs drive.
This operation causes the “SVP Reboot”. Then wait few minutes and reconnect by the remote desktop.
(SVP procedure)
(6) Set IP Address
IP Address must be 126.255.254.15 and Subnet mask must be 255.0.0.0. Also, “Target” must be “SVP”.
(Donʼt select “SVP and DKC” as the “Target”. (INST(IN)14-02-40) (*1)
Besides, do not select “Use Duplex SVP” in the “External IP Address” box.
Cong BackUp is accompanies.)
(SVP procedure)
(7) Delete LOGs.
<Log Delete: (SVP02-03-10), SIM Log Complete: (SVP02-08-10)> (*2)
(8) Set the SVP PS ON/OFF INH switch on the SSVP to OFF (upper position).
When the Additional SVP is installed, set the SVP PS ON/OFF INH switch on the SSVP1 to OFF (upper position).
(9) Set all packages to be installed.
Set the packages (CHB, DKB and so on) to be installed to their locations of CTLs.
(LOC02-140)
