[2] Set IP Address
NOTICE:
• When the SVP High Reliability Kit is installed, setting of the IP addresses for both
Master SVP and Standby SVP is required.
Firstly set IP Address of Standby SVP.
After completing it, please set the IP Address of Master SVP.
SIM = 740300, 740301, 7200, and 7201 might occur during setting operation. If
the SIMs occur, complete them after performing the procedure in this section, and
then execute the LAN check (DIAG03-10). If there is a blinking part in the result
window of the LAN check, see “Recovery Procedure for Error Parts Detected by
LAN Check” (TRBL02-04-440).
• Do not change the Internal LAN setting from [Auto Negotiation].
1. Change the mode to [Modify Mode] from [View Mode].
When SVP is Standby SVP, message [SVP4283W] is displayed, click [OK].
2. Click [Initial Setting].
3. Click [Set IP address] in the Initial Setting window.
To Next Page
