Hitachi DKC910I - Page 20

Copyright © 2019, 2021, Hitachi, Ltd.
DKC910IHitachi Proprietary
[INST(IN)02-03-40]
Rev.1
INST(IN)02-03-40
1. Conrmation of Rack Frames Installation Location
(1) Conrm the Rack Frames installation location and the Side Covers installation position.
(2) When the Side Covers are needed to remove, remove the Side Covers referring to Figure 2-15.
Figure 2-8 Removal and Re-installation of Side Cover
Side Cover Side Cover
Side Cover Side Cover
