(3) Connect the rear of the rack frames with the two joint plates and the eight screws.
(4) Reinstall the two panels that is removed on the procedure a, and secure them with the two screws.
(Refer to Figure 2-12.)
Figure 2-14 Connection of Rack Frames (Rear)
Rack Frame
Screw
(SC520N)
Rear View
Joint Plate
Joint Plate
Screw
(SC520N)
To Next Page
