ABOUT THE SYSTEM SYSTEM FEATURES
1-4
Storage
(16) 2.5” hot-plug SATA/SAS HDD/SSD or NVMe SSD for system:
NVMe SSD 0~15 while four CPUs installed
SATA SSD/HDD 0~11 only
SAS/SATA SSD/HDD 0~15 while SAS HBA/RAID card installed
Onboard storage
(2) PCIe x1 / SATA M.2 2280/22110 slot
The PCIe connectivity of M.2 slot is designed in PCIe Gen3 x1 lane and highly
recommended to install your M.2 SSD as the boot drive.
HDD backplane 1 to 1
Video Integrated Aspeed AST2500 with 8MB DDR4 video memory
HW RAID options QS-3516B SAS 12Gb/s mezzanine RAID card, support RAID 0, 1, 5, 6, 10, 50, 60
Network options
(1) GbE dual or quad port OCP mezzanine PHY card (Optional)*
(1) 10GbE dual or quad port OCP mezzanine PHY card (Optional)*
For more options refer to support.HitachiVantara.com
*The dual or quad port PHY card is installed to OCP mezzanine slot
Front I/O (1) USB 2.0 port
Back I/O
(2) USB 3.0 ports
(1) VGA
(1) Micro-USB port (for console)
(1) MicroSD slot
(1) GbE RJ45 management port
TPM Yes (optional, SPI mode)
ACPI ACPI compliance, S0, S5 support
Power supply
(2) 2200W high efficiency hot-plug redundant PSUs*
200~240VAC, 50/60HZ, 14A MAX
240VDC, 14A MAX
*This is conditional support for 1+1 redundant PSU. Your system can fully run
with no limitation when these two PSUs work normally. The system would
initiate power management to decrease the power consumption under a one
PSU limitation if one of the PSUs failed
.
System rating 200-240Vac, 11A, 50/60Hz
Fan (
5) Easy-service redundant rotors fan modules
System management IPMI v2.0 Compliant, on board "KVM over IP" support
Table 1.1: System Specifications (Continued)
SPECIFICATIONS DESCRIPTION
