1-20
(3) Set rotors.
Two rotors are packed together as accessories: Put one rotor each into ink
reservoir and main ink tank before adjusting air pressure.
(4) Input pressure adjustment
Adjust so that scale of filter regulator is 0.1 (+0.01) MPa. If pressure is
insufficient, rotor may not rotate.
Perform adjustment with stirrer being rotated.
Refer to “ 1.2.7. Confirming air supply for stirrer and operation” in the instruction
manual for driving method of stirrer.
Caution
If a rotor is not in the tank, stirrer will be rotating at high speed.
Caution
！
Pressure adjustment range
