Fix Unit to the wall
Fix the Unit onto the wall as the gure
indicates. (eld supplied stay)
Ensure the foundation so that avoid the
deforming and noise.
In case of prevention from vibration
transfer to the building, use rubber Mat.
Rubber Material
(Field Supplied)
Suspended unit
Suspend the unit as the drawing
indicates.
Ensure that wall can resist the Outdoor
unit weight indicated in specication label
plate.
It is recommended to select each foot
support to bear the full weight of the unit
(in order to consider stress fatigue applied
when unit is working too).
Wall bracket (*)
Anchor Bolts (*)
(*) Field supplied
! CAUTION
• Payattentiontothefollowingforinstallation:
• Installation shall ensure that outdoor unit
will not incline, vibrate,make noise or fall
downbyablastofwindorinanearthquake.
Calculate quake-resistance strength to
ensure that installation is strong enough
againstfalling.Fixtheunitwithwires(eld
supplied) when installing in a location
without walls or windbreak and likely
exposedtoablastofwind.
• Touseavibration-proofmat,xfourplaces
tothefrontandback.
Installing location where the unit will be exposed to strong wind
Follow the instructions below to install
on the rooftop or a location without
surrounding buildings, where strong wind
is expected against the product.
Choose a location where the outlet
or inlet side of the product will not be
exposed to strong wind.
When the outlet is exposed to strong
wind:
Direct strong wind may cause lack of air
ow and adversely affect to the operation.
! CAUTION
Excessivestrongwindagainsttheoutdoorunit
outletmaycauseinverserotationanddamage
thefanandmotor.
UNITS INSTALLATION
