Hitachi UTOPIA IVX STANDARD Series User Manual

7 UNITS INSTALLATION
7.1 OUTDOOR UNITS INSTALLATION
! CAUTION
• Transporttheproductsasclosetotheinstallationlocationaspractical
beforeunpacking.
• Donotputanymaterialontheproducts.
• Applyfourliftingwiresontotheoutdoor,whenliftingitbycrane
! CAUTION
• Install the outdoor unit with sufcient clearance around it for
operation and maintenance as shown in the next gures.
Installtheoutdoorunitwheregoodventilationisavailable
• Donotinstalltheoutdoorunitwhereisahighlevelofoilmist,saltyair
orsulphurousatmosphere.
• Installtheoutdoorunitasfaraspractical(beingatleast3 meters)
fromelectromagneticwaveradiator(suchasmedicalequipment).
• Forcleaning,usenoninammableandnontoxiccleaningliquid.Use
ofinammableagentmaycauseexplosionorre.
• Workwithsufcientventilation,forworkinginanenclosedspacemay
causeoxygendeciency.Toxicgasmaybeproducedwhencleaning
agentisheatedtohightemperatureby,e.g.,beingexposedtore.
• Cleaningliquidshallbecollectedaftercleaning.
• Payattentionnottoclampcableswhenattachingtheservicecoverto
avoidelectricshockorre.
! CAUTION
• Keepclearancebetweentheunitsofmorethan100mm,andavoid
obstaclesthatmayhamperairintake,wheninstallingmorethanone
unitstogether.
• Installtheoutdoorunitintheshadeornotexposedtodirectsunshine
ordirectradiationfromhightemperatureheatsource.
• Donot installthe Outdoor Unitin aspace where a seasonal wind
directlyblowstotheOutdoorfan.
• Check to ensure that the foundation is at, level and sufciently
strong.
• Installtheunitinarestrictedareanotaccessiblebythegeneralpublic
• Aluminiumnshaveverysharpedges.Payattention to the ns to
avoidinjury.
7.1.1 Installation space
(Unit: mm)
Blocked in Inlet Side
Upper Side Open
Single Installation Multiple Installation (Two units or more)
*
*
Front Side
Front
Side
Front Side
Front Side
Upper Side Blocked
Single Installation Multiple Installation (Two units or more)
UNITS INSTALLATION
PMML0395B rev.0 - 11/2015
6
