D2 Drive User Guide v1.8 4. Wiring
HIWIN Mikrosystem Corp. 56
(5) Connector kit
Table 4-19
D2 Drive model
Model No.
Description
Quantity
Frame A-C
D2-CK3
CN1: Connectors of AC power, motor power,
regenerative resistor, and control power. 12 pins, pitch
5 mm, Wago 721-112/026-000.
1
CN2: Brake connector. 4 pins, pitch 3.5 mm
1
CN6: Control signal connector. 50 pins, welded type,
EUMAX XDR-10350AS.
1
CN1 connector fixture tool: Wago 231-131.
1
CN2 connector fixture tool: Wago 734-230.
1
Frame D
(with Modbus
interface)
D2-CK4
CN1: Connectors of AC power, drive control power,
regenerative resistor, and DC reactor. 11 pins, TE
1-2229794-1-PT1.
1
CN2: Motor power connector. 3 pins,
TE 3-22297894-1.
1
CN4: Connector kit for serial communication.
TE 2040008-1.
1
CN5: Safety function connector. TE 1971153-1.
1
CN6: Control signal connector. 50 pins, welded type,
EUMAX XDR-10350AS.
1
CN1 and CN2 connector fixture tools: TE 1981045-1.
2
Frame D
D2-CK5
CN1: Connectors of AC power, drive control power,
regenerative resistor, and DC reactor. 11 pins, TE
1-2229794-1-PT1.
1
CN2: Motor power connector. 3 pins,
TE 3-22297894-1.
1
CN5: Safety function connector. TE 1971153-1.
1
CN6: Control signal connector. 50 pins welded type,
EUMAX XDR-10350AS.
1
CN1 and CN2 connector fixture tools: TE 1981045-1.
2
(6) EMC accessory kit
Table 4-20
Part name
Model No.
Description
Quantity
D2 EMC
accessory kit for
single phase
D2-EMC1
Single-phase filter: FN2090-6-06 for 50 W to 400 W.
(Rated current: 6 A, leakage current: 0.67 mA)
1
EMI core KCF-130-B.
2
D2-EMC3
Single-phase filter FN2090-10-06 for 750 W to 1 KW.
(Rated current: 10 A, leakage current: 0.67 mA)
1
EMI core KCF-130-B
2
D2 EMC
accessory kit for
three-phase
D2-EMC2
Three-phase filter: FN3025HL-20-71.
(Rated current: 20 A, leakage current: 0.4 mA)
1
EMI core KCF-130-B.
2
D2-EMC4
Three-phase filter B84743C0035R166.
(Rated current: 35 A, leakage current: < 0.5 mA)
1
EMI core KCF-130-B
2
Note. The EMI magnetic ring can reduce the noise interference, and can be applied on the main power
cable, motor power cable, encoder cable, or pulse control cable based on demand.
