Basic Operation - Unbalance Display MC10 HS
4 - 14
4.5.5 Command Bar
The command bar features shortcuts for Main Menu
commands on the left hand side. This area has a dif-
ferent allocation depending on the display.
Fig. 4-3: Command bar on the measuring screen
1 - Shortcuts to Main Menu
2 - Fixed keys:
ļ The shortcut keys appear in the colour of the
active access group (refer to Chapter 5.6 - Ac-
cess Privileges).
Last Screen Opens last shown screen.
Hardcopy Send a hardcopy of the screen to the
printer. (Option)
Print Generate report. Refer to Chapter 6.2
- Generating a Report. (Option)
"Manual Mode" or
"Automatic Mode" or
"Automatic active"
Display of the current operating mode.
