Insight FD Mini C-Arm Imaging System User Guide
Using the System
19 MAN-09971 Revision 001
Figure 9 Sterile C-arm Drape
Powering Up the System
The system should be at ambient room temperature.
The power cord must be plugged into a standard single-phase three-wire
grounded outlet. A special dedicated outlet is not required.
To power up the system, press the Computer On/Standby switch.
Fluoroscan Insight will prompt the user to login.
If the system has been off for more than two weeks, use the following
source conditioning procedure to safeguard and prolong the life of the X-
ray source:
Warning: The Insight system operates on standard 115 Volt, 60 Hz AC
power for United States, Japanese and Canadian models, 230 Volt,
60 Hz AC, and 240 volt, 50 Hz AC power for other export models.
• The system should only be plugged into a properly
grounded three-wire wall outlet.
• Never cut the third (grounding) pin from the power
cord to plug the unit into an ungrounded two wire
outlet. Never use a three wire-to-two wire adapter.
