Insight FD Mini C-Arm Imaging System User Guide
Configuring the Application
MAN-09971 Revision 001 24
Table 9 DICOM Send Options Page
Section/Field Description
Configure DICOM
Send Destinations
Selection list of DICOM Send destinations configured on the
system and six function buttons.
When checked, the Active column check box enables
destination for use.
Add/Edit
Destination
Entry/edit fields to identify a DICOM Send destination, three
check boxes, and two function buttons.
AE Title Destination’s Application Entity Title.
Host Name or IP
Address
Destination’s Name or IP address.
Port Destination’s Port number.
Use as Storage
Commitment
Provider
When checked, indicates the destination is committed to storing
information sent to it.
During a normal shut down, if any DICOM Commit queue
entries are greater than 7 days old, a message box appears
indicating: DICOM Storage Commitment Queue contains
entries older than 7 days. DO you want to delete them?
Include Raw Data When checked, indicates studies sent to the destination shall
include the raw data.
Include Annotations When checked, includes annotations with exported images.
Method of inclusion choices are:
Embedded - Annotations are embedded into the bitmap image.
As Overlay -Annotations are included as a DICOM overlay.
As annotation files - Annotations are included as a separate file.
Table 10 DICOM Send Options Page, Button Functions
Button Function
Add
Destination
Adds a DICOM Send destination to the system.
Edit
Destination
Edits selected destination information.
Delete
Destination
Deletes selected destinations from the system.
Local Ping Confirms connection to the local network.
Remote Ping Confirms network connection to the selected destination.
