Insight FD Mini C-Arm Imaging System User Guide

Using the Insight Application

39 MAN-09971 Revision 001

Figure 21 System Configuration Pull-down Menu

G Close the Application screen (unavailable)

H Help - Displays help for using the screen.

I Starts an image acquisition session (Image Acquisition Session on Page 44)

J Starts an image review session (Review Screen on Page 54)

K Exits application and shuts down the system.
