Insight FD Mini C-Arm Imaging System User Guide
Configuring the Application
35 MAN-09971 Revision 001
Enhancement
Select Edge or Sharpen from the dropdown list. Edge enhancement
increases visualization between bone and soft tissue in the image.
Sharpening enhancement increases visualization of fine detail. On/
Off or Disabled affects the “image effects settings” in the Image
Acquisition screen.
Reverse Video Select On/Off or Disabled, which affects the “image effects
settings” in the Image Acquisition screen.
Image Flip Select On/Off or Disabled, which affects the “image effects
settings” in the Image Acquisition screen.
Dark Fluoro Select On/Off or Disabled, which affects the “image effects
settings” in the Image Acquisition screen.
Initial Image
Rotation
Enter number of degrees to automatically rotate an image while it
is being acquired. Enter a negative number for counterclockwise
rotation.
Brightness/
Contrast
Adjustment
Remember settings between sessions - When checked, maintains
Brightness/Contrast settings for subsequent images.
Apply Auto Equalization after acquisition - When checked,
applies Auto Equalization to the image to optimize contrast.
Table 20 Physician Preferences, Image Processing Tab, Section/Field Descriptions
Section/Field Description
