Insight FD Mini C-Arm Imaging System User Guide
Using the Insight Application
55 MAN-09971 Revision 001
Full View Displays the selected image in the Enhanced Displayed Image
screen. See “Enhanced Displayed Image Screen” on page 57.
Save Saves selected images or cine loop to the patient’s record.
If the number of stored images or minutes of cine loop exceed the
storage limit, a message is displayed.
Delete Deletes the selected images. If the system setting Query on Delete is
enabled, the user is asked to confirm the deletion. Click Yes to
confirm; No to cancel the deletion.
Export Copies the selected image(s) or cine loop to removable media.
Patient information will be removed from images when De-Identify
Patient Information is checked.
Print Prints the selected image(s) to the local printer
Images will be printed with annotations when Display/Print
Annotations is checked. Patient information will be removed from
images when De-Identify Patient Information is checked.
DICOM Print Sends the selected images to a DICOM node printer for printing.
Images will be printed with annotations when Display/Print
Annotations is checked. Patient information will be removed from
images when De-Identify Patient Information is checked.
DICOM Send Sends the selected image(s) to a DICOM Send node. Patient
information will be removed from images when De-Identify Patient
Information is checked.
View Queue Displays the status of all DICOM Send requests. See “View DICOM
Queue Window” on page 67.
Patient Details Displays patient information. Click Additional Details to reveal
Vista Dialog (Figure 33).
DAP Report Displays the DAP report for the selected patient.
Note: Click DICOM Send, on the DAP Report display screen, to
send the DAP Report to a DICOM destination.
De-Identify
Patient
Information
Omits protected patient health information details related to
specific patients.
Update Patient /
Select Study
In an acquisition session, returns to the Select or Enter Patient
window to view or update patient information
In a review session, returns to the Select Patient for Review
window to select a different patient study.
Table 38 Review Screen, Button Functions
Button Function
